10.0HDKCC-42345  10.0HDKCC-4512

ONAN QD 10000 is powered by a Kubota D1503-M model, featuring a 4-cycle, liquid-cooled diesel engine with 4 inline vertical cylinders. It includes a brush-type AC alternator with digital voltage regulation and built-in self-diagnostic capabilities. The design features a bottom air inlet and outlet configuration, an integral enclosed muffler with a stationary exhaust pipe connection, and a USDA-approved spark arresting muffler. Additional components include an internal radiator, sound-attenuated housing, intake silencer, heavy-duty air cleaner, and maintenance-free electronic governor. The system also offers regulated-voltage 15A battery charging, hour meter, and waterproof connector for remote operation. A four-point, fully focalized internal mounting system reduces vibration, and it includes safety features such as over voltage, low oil pressure, and over-speed protection.

GENERATOR SPECIFICATIONS

MAXIMUM RATING        VOLTAGE            FREQUENCY

10KW                              240 V                    60 HZ

NEW GENUINE / REMAN

Quiet Diesel Series 11 QD Model HDKBN features computer-controlled constant speed operation and a unique sound-controlled housing with sound shields that minimize noise while enhancing sound quality. Its four-point semi-focalized internal mounting system significantly reduces vibration, and self-diagnostic capabilities simplify troubleshooting. An optional Cummins Onan digital display offers user-friendly diagnostics, including detailed engine and alternator information, self-diagnostic features, and a text display. Service and maintenance points are easily accessible through a side service door with a latch, and control panel-mounted switches provide added convenience. The automatic glow plug eliminates preheat time uncertainty. The design includes a 4-cycle, IDI water-cooled diesel engine with 4 cylinders.

GENERATOR SPECIFICATIONS

MAXIMUM RATING       VOLTAGE          FREQUENCY

11KW                              240 V                 50 HZ

NEW GENUINE / REMAN

12.0HDKCD-2209   12.0HDKCD-5241

Onan QD 12000 features a Kubota D1503-M model with a 4-cycle, liquid-cooled diesel engine, and 4 inline vertical cylinders. It includes a brush-type AC alternator, digital voltage regulation, built-in self-diagnostics, an internal radiator, sound-attenuated housing, and a USDA-approved spark arresting muffler. Key components also include a maintenance-free electronic governor, regulated-voltage 15A battery charging, and an hour meter. The four-point internal mounting system reduces vibration, while safety features include protection against over-voltage, low oil pressure, and over-speed. Service is simplified with side access, and the system has automatic glow plugs for quick starts and an instant one-touch stop function.

GENERATOR SPECIFICATIONS

MAXIMUM RATING       VOLTAGE           FREQUENCY

12KW                              240 V                  60 HZ

NEW GENUINE / REMAN

Quiet Diesel Series 13.5 QD Model HDKBP features advanced digital electronic control with extensive diagnostic capabilities, including shutdowns for high engine coolant temperature, low oil pressure, over-speed/voltage, and starter overcrank. It has a start-run-stop switch with glow plug preheat and fuel pump priming modes for easy starting, and automatic glow plug preheat for cleaner starts. The electronic governor ensures precise frequency and voltage regulation for quality power. The generator includes a single-phase brushless AC alternator, digital voltage regulator, 12V DC electric system, and electric fuel transfer pump. It also has a cooling system with remote heat exchanger, water-cooled exhaust manifold, full-flow lube oil filter, and oil drain extension. Additional features include a running time meter, vibration isolators, fuel filter/water separator, and a drip pan base. The design incorporates bulkhead-type connections, a single-point lifting bracket, and a closed crankcase breather for easy installation and maintenance. Powered by a 4-cycle, IDI water-cooled diesel engine with 4 cylinders, the system is factory load tested and includes a fire extinguisher access port.

GENERATOR SPECIFICATIONS

MAXIMUM RATING                 VOLTAGE             FREQUENCY

13.5KW                                    416 V                     50 HZ

NEW GENUINE / REMAN

Quiet Diesel Series 17.5 QD Model HDKBR features advanced digital electronic control with diagnostic capabilities and shutdowns for conditions like high coolant temperature, low oil pressure, and over-speed. It includes a start-run-stop switch with glow plug preheat and fuel pump priming, along with automatic glow plug preheat for cleaner starts. The electronic governor ensures precise frequency and voltage regulation. Key components include a brushless single-phase AC alternator, digital voltage regulator, 12V DC system, electric fuel transfer pump, and remote cooling system. Powered by a 4-cycle, water-cooled diesel engine with 4 cylinders, the system offers easy installation with bulkhead-type connections, a single-point lifting bracket, and a drip pan base for fluid containment, all backed by factory load testing and a closed crankcase breather.

GENERATOR SPECIFICATIONS

MAXIMUM RATING      VOLTAGE           FREQUENCY

17.5KW                         416 V                   50 HZ

NEW GENUINE / REMAN
